Description
Superior Features
- Vacuum Source: Electrical Vacuum suction pump for filtration with Help of Pressure Mode.
- Fixed filtration glass chamber in the filtration module, Size: 500(D) X 465(H) X 482(W)
- Sample loading: Individual sample loading with independent mechanical control
- Control valves: Individual control valves for vacuum and filtration
- Uniquely designed expansion vessel to feed samples after enzymatic digestion & residue collection vessel
- Counter pressure option with reverse air stream, Essential Accessories like Crucible Rubber, Extractor Rubber, Teflon Bush & Nylon Bush
- Bath designed for studies on Tissue metabolism, Enzymes and Protein coagulation & experiments requiring
- Shaking of subject matter at constant speed under controlled temperature environment.
- System consists of stirring in SS water tank with reciprocal motion with thermostatic heating bath.
- Enzymatic digestion vessel. Microprocessor based Digital PID Temperature controller with auto tuning facility
- Temperature Range : Ambient to 110°C, Temperature Setting: 1°C.
- Strokes:0-120 strokes/minute continuously variable.
- Drive: Heavy duty DC motor designed for uniform noiseless motion.
- Shaking speed can be controlled by means of Electronic Speed Controller cum Digital Indicator upto 150 RPM.
- Speed Indication: Digital LED Display, Heater: Immersion heater thermostatically controlled.
- Water Bath tank made of Stainless Steel-316 grade and Exterior of Stainless Steel-304 grade.
- High density glass wool insulation to prevent heat loss & ensure constant temperature
- Shaking tray consist of Lotus clamps to hold Erlenmeyer flasks.
- High grade Silica glass Crucible with P2 (P100) Disc ,40-90 μm Microns for free flow of reagent while operation.
- Speed setting with Rotary potentiometric knob for continuously variable speed
- Timer inbuilt digital timer:0 to 99.59 Settable in Hrs. Mins & Secs
- Speed Indication Digital Display with LED indication
- High grade Silica glass Crucible with P1 grade disc,40-90 μm Microns(70mm height) Optional (P0/P2) for free flow of reagent while operation.
Safety Features
- Over temperature protection, Auto error Indication, Sensor breaks protection.
- Heater cut off feature with buzzer indication and alarm, Acoustic signals with visual display
- Auto tuning facility, Anti vibration mount, Auto stop & Start feature
