Description
Superior Features
Temperature Control Range: Ambient to 650 ° C, Temperature Accuracy:±1°C,control with knob
Time & Temperature Readout in the LCD Display System.
Multi Functional Programmable Sets Temperature & Time to Control Heaters for Inorganic acid Digestion.
Auto Sequencing Temperature/Time domain of 10 Microprocessor Program with 5 desire ramp/Stage step.
Versatile digestion tubes of 100ml, 300ml, 400ml and 800 ml volume upgrade.
Two tier console: Compact design to place Insert rack and Manifold Rack with exhaust manifold, Drip
Facility of storing the drip tray within the unit only to reduce the bench space.
Tray, Shield plate & Standby mode for easy handling of tubes, Auto temperature cut-off.
Allow measuring the actual temperature with an external thermometer.
All essential accessories like Digestion Tubes, acid proof SS Insert Rack, Exhaust Manifold, Suction assembly for safe removal of acid fumes with easy drain Suction pump wall mounted in the system for safe removal of acid fumes & easy drain.
Safety Features
- Auto Calibration of casted Heater Temperature
- over Temperature Protection
- Auto High temperature warning
- Auto Sensor Break Protection
- Auto over Temp. Cut off, Auto Error Indication, Auto Alarm.
- Overload Protection, Over Current Protection
- Auto Sensor Break Detection
Automatic Scrubber System
KjelSCRB –Acid Neutralizer Three Stage Scrubbing System
Number of Stage gas Scrubbing System: Three
First Stage: Neutralization in Alkali
Second Stage: Neutralization in water
Third stage: Dissolution in Raw water
Non Corrosive – chemical Resistant Magnetic centrifugal suction PVC Self priming water recirculation pump. Non corrosive submersible pump for condenser water circulation
Vacuum source: Non corrosive Aspirator filter pump for vacuum. capacity of at least 8 litre
Recirculation in 8 litres stainless steel tank avoids requirement of running water during digestion
Automatic water level indicator to view water level in SS tank externally.
Electrical Requirement: 230 Volts, 50-60 Hz
Accessories
Borosilicate Alkali with 2 Ltr Container
Borosilicate Water with 2 Ltr Container
Rapid Automatic Protein Distillation System
MODEL KjelDIST AT : FULLY AUTO NITROGEN/PROTEIN DISTILLATION SYSTEM (ISO 9001:2015 & CE Certified ) (The Rapid Fully Auto Run completely Microprocessor Programmable Based PC Compatible Auto Sequence Operation TFT Touch screen Display Distillation System with 100 Programmable user In built Software) Graphical Color Touch Screen Display High Resolution TFT Display 7’ inch Micro controller embedded system.
MOC: Body constructed with Corrosion Free Glass Reinforced polymer Epoxy Coat for Long Durability.
Provision for large selection of sample Versatile tubes & flask of 250 ml, 300ml, 400ml, 750ml & 100ml to 1000ml, Electrical Requirement: 230 Volts 50-60Hz.
Application
Suitable for all type of sample like Solid & liquid, Food & feed, milk, skimmed milk powder, milk products, soil, plant, Water, Pesticides, Fertilizers, Manure, waste water, urea, Bio Material, Fish Meal, Animal Feed, Fodder, Grain, Confectionary, Agricultural, Industrial, Sludge ,Petrochemicals, Chemicals, Leather, Paper pulp and many more.
Pre definable user storage Auto sequence programmes with following Sequence steps
- Auto Addition of Boric acid (Receiver Solution).
- Auto Sample Selection Library
- Auto Addition of Sample Dilution
- Auto Duration of React time
- Auto Duration for delay time
- Auto Addition of NaOH (Alkali)
- Auto Duration of Neutralization
- Auto Addition of water Steam injection.
- Auto Distillate control with adjustable volume Steps (50,100,150ml etc)
- Auto Duration of Sample Settle Time.
- Auto Process over Intimation with alarm
- Auto alarm for Sequence steps
- Auto Titration Connectivity feature for Future Upgradatiion
- Each Sequence run with inbuilt auto delay time feature
Superior Features
Independent 316 stainless steel non corrosive steam generator , Expansion vessel and water condenser with safety Sensor
Electronic components by provision of over current circuit breaker and SELV (Safety Extra Low Voltage).
Microprocessor Based Programme library Like Soil , Plant , food, Dairy, feed, Grains, starch cereals, fertilizer, water , etc.,
Microprocessor based Adjustable steam power from 10-100% suitable for different applications
Precise dosing pump for reagent addition, Auto inbuilt calibration facility.
Facility to Record and store statistical data of Total running cycle of pumps, Total running time of pumps, Total number of distillation completed with LCD display of all parameters
User Alert Auto Service Maintenance for periodical checking & maintenance of pumps to avoid future repairs.
Auto reagent Level Sensor with Alarm for Reagents tanks to be wall mounted for easy handling and user’s visibility
Dosing Pump operated with 12 Volt for low energy consumption, view a full processing head with illumination (lightning facility) of distillation process.
ISO 17025: 2017 Conformity of data management like Traceability, different user levels with their rights, Password protection, Recording, recalling of required Processed data’s.
PC Software System has capable to store the recorded data and have facility for downloading via USB port for LIMS operation, user level with defined rights and password protection, with date and time and sample ID
Direct calculation of results in LCD touch screen with user programmable formulae for direct reading of Nitrogen, protein, available Nitrogen, etc with inbuilt software
Control panel unit along with inbuilt temperature controller, timer, mother board ,SMPS isolated in separate control Tower compartment to Protect electronics from wet chemistry & acid/alkali process area, with separate access door for main unit & Electronic Control tower unit
Measuring Range: 0.1 to 200 mg Nitrogen, Detection limit: 0.1mg Nitrogen, Nitrogen Reproducibility: ± 1% RSD, Nitrogen Recovery: > 99.5%
Safety Features
Auto tube inserts error indication
Auto online water saving mechanism
Auto deactivation of system on error diagnosis
Interlocked Safety Protection Door With Safety Switch
Automatic Excess pressure release safety valve
Cooling water sensor for No water condensation error
Safety Auto Door Opens warning alarm with Visual Indication
Sequence step intimation alarm/ Indication for User Attention
REFRIGERATED WATER COOLING CIRCULATION SYSTEM
KjelFRIG, the unit Developed by Tulin with high Refrigerated water cooling Circulation System with Digital Display Temperature System. help in efficient Condensation for rapid Soxhlet Unit.
Built in safety Features with CE to fulfill GLP Norms/ Auto over temperature, OLR & Sensor
Break Protection, Auto Error Indication, Over Temp. Cut off, Over load Protection
Microprocessor based PID Temperature Controller, Temperature Range:10°C to Amb-5°C
Recirculation chemical Resistant pump with 10 Liter SS Tank, Submergible pump for recirculation, MS Power coating Housing. Compressor Capacity – l/8 Fan- l0Watts, 1450 rpm.
Offering Considerable saving on water. The type and quality of the materials used make the
Instrument extremely quiet long -lasting and guarantee a high flow rate.
Refrigerated water cooling system with built in compressor and recirculation.
Electrical Requirement :220v/50Hz AC, Compressor Capacity: 1450 rpm.
Nipples for inlet, outlet & overflow Drain -1/2 an inch ball valve
