Description
Process Controller: Large Touch screen LCD display Microprocessor based process controller with PID temperature controller with help guide menu
Control Panel: Common single touch screen controller with options of Digestion& Distillation simultaneously / independently with common controller for Digestion, Distillation and Scrubber
Mode of operation: Auto mode and Manual mode
Digestion Heating block: Extruded Aluminum block with proper insulation to avoid heat dissipation.
Digestion Heater: Casted Aluminum alloy heater for uniform heating. Digestion Heater wattage:1500 W
Digestion Temperature controller: Microprocessor based PID Temperature controller with Touch Panel with auto tuning facility
Temperature Range of Digestion: 5°C above the Ambient (Room Temperature) to 450°C with safety cut off at 440°C (As per Kjeldhal method effective digestion takes place 380°C – 420°C)
Digestion temperature accuracy: ± 1%
Digestion temperature sensor: K type thermocouple
Digestion program: Auto sequencing programmed of integrated time temp. domain
Digestion program parameter: Integrated Time and Temperature programming ramps
Digestion block insulation: Ceramic Glass wool & Cynthanium
Digestion acid fumes removal: Glass manifold with Teflon adaptors fitted on to a SS rack
Two tier console: Compact design to place Insert rack and Manifold Rack above digester in combined three-in-one unit with exhaust manifold & drip tray.
Digestion tube insert Rack: Stainless steel
Digestion Manifold Rack: Stainless steel
Digestion Drip Tray: Stainless steel
Accessories: Includes all essential accessories for full fledged working of the system
Exhaust fume condensation: Dissolution in water in SS tank with auto drain
Scrubber tank: Non corrosive FRP Tank
Scrubber water leveler: Float switch with sensor
Scrubber tank capacity :8 litres
Scrubber suction pump: Giant filter pump
Scrubber water recirculation pump: Anti corrosive Magnetic suction pump for water recirculation
Scrubber inbuilt timer & auto drain of tank: Integrated automatic scrubber with inbuilt timer with auto drain of tank water after every batch of digestion.
No of distillation: One at a time
Distillation Programmed steps: Auto sequencing addition of KMnO4, Alkali & Steam processing with inbuilt delay time & auto shutdown of process
Alkali Dosing pump: Peristaltic Pump
Distillation steam Generator: Stainless steel generator with transparent window for viewing glass condenser
Nitrogen Level:0.1 to 200 mg Nitrogen (Min / Max Detection Limit)
Nitrogen reproducibility: ± 0.1% RSD
Nitrogen recovery> 99.5%
Distillation expansion vessel: Glass with Teflon insert for alkali addition
Distillation water condenser: Uniquely designed Glass condenser
Distillation solenoid valves: For Steam, Refilling and Vent
Distillation Heater: Immersion Heater
Distillation Heater Wattage :1500 W
Distilled water tank :PP Tank(Polypropylene)
Distilled water tank capacity:5 Lit
Distillation Reagent tank PP Tank(Polypropylene)
Distillation Reagent tank capacity:2 lit
Other Features
- Acoustic and Visual Error Indication, Damaged probe detection, Run completed alert, Auto scrubber on/ off with delayed off timer
- Automatic cooling water cut off post process completion for water saving
- Temperature controller & electronics housing are isolated from the main extraction unit for safe operation
- Transparent window to watch process of distillation and splash head
- Water in the scrubber tank is drained and filled automatically every time at the end of digestion thereby draining the acidic water.
- Manual drain of water from the scrubber tank is provided, additionally
- A separate distilled water line to the steam generator.
- Auto refilling of distilled water to the steam generator with proximity sensor.
- Boiler water level monitoring external view window.
- Users choice to choose independent or combined operation of digestion and distillation.
- Inbuilt safety features
- Over voltage Circuit breaker
